Bay–related parameters
6400 SETTINGS: StatusBay 01–48?
6401 STATUS B 01 =active (inactive, active)
6402 STATUS B 02 =active (inactive, active)
.
.
.
6448 STATUS B 48 =active (inactive, active)
6500 SETTINGS: I>TripBay 01–48?
6501 I>TRIP BAY01 =.00 I/IN
1)
(min. 0.00 – max. 25.00)
6502 I>TRIP BAY02 =.00 I/IN
1)
(min. 0.00 – max. 25.00)
.
.
.
6548 I>TRIP BAY48 =.00 I/IN
1)
(min. 0.00 – max. 25.00)
6600 SETTINGS: BF OpMode 01–48?
6601 BF OPMD B01 =BZ unbalance (not existent, external,
BZ unbalance, trip rep/unbal, I>query,
trip rep/I>quer, trip rep/unb imp)
6602 BF OPMD B02 =BZ unbalance (like DA 6601)
.
.
.
6648 BF OPMD B48 =BZ unbalance (like DA 6601)
6700 SETTINGS: I>BF Bay 1–48?
6701 I>BF BAY 01 =.50 I/IN
1)
(min. 0.10 – max. 2.00)
6702 I>BF BAY 02 =.50 I/IN
1)
(min. 0.10 – max. 2.00)
.
.
.
6748 I>BF BAY 48 =.50 I/IN
1)
(min. 0.10 – max. 2.00)
_______________
I
N
– Nominal current of the bay current
transformer
