Appendix
A
A - 17
Siemens AG ⋅ May 1998
A.1.5 Pre-setting of binary inputs and outputs
Table A.9.5 Pre-setting of annunciation relays and LED's of master unit
LED- and
alarm
relay-No
Logical function FNo Short text
(text on LC display)
1 Failure with protection blocking 000 Err. PROT BLOCK
2 Failure without protection blocking 001 Err. PROT ACTIVE
3 Diff current supervision selective
1)
92 Id-sup BZ01 L1 -2 to Id-sup BZ12 L1 -2
Id-sup BZ01 L2 -2 to Id-sup BZ12 L2 -2
Id-sup BZ01 L3 -2 to Id-sup BZ12 L3 -2
Id-sup BZ01 L1 -3 to Id-sup BZ12 L1 -3
Id-sup BZ01 L2 -3 to Id-sup BZ12 L2 -3
Id-sup BZ01 L3 -3 to Id-sup BZ12 L3 -3
4 Diff current supervision check zone 093 - 095 diff sup CKZ L1; 2; 3
5 Cyclic test failure identified
2)
205 Flt aut L1 -1; 2; 3:BXY
Flt aut L2 -1; 2; 3:BXY
Flt aut L3 -1; 2; 3:BXY
6 Isolator failure (plausibility check CLOSED, OPEN
simultaneously, running time supervision)
084 085 Isoly Flt pla:BXY
Isoly Flt run:BXY
(y = 1 ... 5)
7 Isolator failure-auxiliary voltage failure 086 Bay DC Fail:BXY
8 Circuit breaker failure 087 CB fail:BXY
9 Measured value supervision 192 Meas in sup:BXY
10 Supply voltage supervision FE 193
195 206 207
15V-superv.:BXY
0V-superv.:BXY
15V-superv.CU
24V-superv.CU
11 Bay out of service 015 out of serv.:BXY
12 Binary input breaker failure, time exceeded 009 - 012 BF Bl err:L1; 2; 3:BXY
13 Fault record buffer blocked 089 Flt rec blocked
14 TRIP repeat 028 044 060 TripRepL1; 2; 3:BXY
15 Breaker failure / transfer trip 029 transf Trp:BXY
16 TRIP busbar "high-speed TRIP"
3)
030 TRPBZ01 L1 = zzz - TRPBZ12 L1 = zzz
TRPBZ01 L2 = zzz - TRPBZ12 L2 = zzz
TRPBZ01 L3 = zzz - TRPBZ12 L3 = zzz
zzz = Fault-No.
17 Busbar protection TRIP command BZ1 016 032 048 TRPBZ01 L1; 2;3=zzz
18 Busbar protection TRIP command BZ2 017 033 049 TRPBZ02 L1; 2;3=zzz
19 Busbar protection TRIP command BZ3 018 034 050 TRPBZ03 L1; 2;3=zzz
20 Busbar protection TRIP command BZ4 019 035 051 TRPBZ04 L1; 2;3=zzz
21 Busbar protection TRIP command BZ5 020 036 052 TRPBZ05 L1; 2;3=zzz
22 Busbar protection TRIP command BZ6 021 037 053 TRPBZ06 L1; 2;3=zzz
23 Busbar protection TRIP command BZ7 022 038 054 TRPBZ07 L1; 2;3=zzz
24 Busbar protection TRIP command BZ8 023 039 055 TRPBZ08 L1; 2;3=zzz
25 Busbar protection TRIP command BZ9 024 040 056 TRPBZ09 L1; 2;3=zzz
26 Busbar protection TRIP command BZ10 025 041 057 TRPBZ10 L1; 2;3=zzz
27 Busbar protection TRIP command BZ11 026 042 058 TRPBZ11 L1; 2;3=zzz
28 Busbar protection TRIP command BZ12 027 043 059 TRPBZ12 L1; 2;3=zzz
1) FNo. 92: Diff. current supervision selective
Collective alarm comprises the single alarms according to table 6.2 on
page 6-24.
2) FNo. 205: Periodical test alarm
Collective alarm comprises all single alarms according to table 6.2 on
page 6-24.
3) FNo. 30: "high-speed TRIP"
common alarm for TRIP command alarm FNo. 16 - 27; 32-43 and
48-59. Recognition of the alarm "high-speed TRIP" runs with a resoluĆ
tion of 1 ms. Marshalling of this function to alarm relays is possible.
