6.4.2.3 Marshalling of the alarm relay - block 62
The bay unit has one freely marshallable alarm output,
designated with ALARM RELAY 1. Marshalling is carĆ
ried out under DA 6201/FE.
Several logical functions (up to 20) can be marshalled
to the alarm output.
Table 6.8 shows the complete list of all available
alarm functions with indication of the function number
FNo.
Alarms beginning with ">" are direct checkback siĆ
gnals of the binary inputs and are identical to them.
They appear as long as the corresponding binary input
is active.
The alarm relay is pre-set with "Bay out serv"
(FNro 7080/FE).
Table 6.10 Marshallable output functions
FNo Short text
(indication on LC-display)
Logical functions
1
5
161
190
356
1156
7000
7001
7002
7003
7004
7005
7006
7007
7008
7009
7020
7021
7022
7023
7024
7025
7026
7028
7029
7030
7040
7050
7051
7052
7053
7060
7061
7062
7070
7080
not marshalled
>LED-ackn
Meas val Sup
Fail com.CU
>CB CLOSE com
>CB test
>Isol1-Closed
>Isol1-Open
>Isol2-Closed
>Isol2-Open
>Isol3-Closed
>Isol3-Open
>Isol4-Closed
>Isol4-Open
>Isol5-Closed
>Isol5-Open
>CBF L1
>CBF L2
>CBF L3
>CBF pulse
>CBF Rel
>AUS Rel
>CB OPEN
>CB Disturb
>Bay out serv
BBP start
BBP TRIP L123
CBF TRIP L123
CBF TRIP L1
CBF TRIP L2
CBF TRIP L3
CB aut TRIP L1
CB aut TRIP L2
CB aut TRIP L3
BBP TRANSTRIP
Bay out serv
No function allocated to output
>reset LED indications
Measured value supervision
Data communication to master unit disturbed
>Close command to bus coupler circuit breaker
>start three-pole circuit breaker test
>Isolator status signal Closed for isolator 1
>Isolator status signal Open for isolator 1
>Isolator status signal Closed for isolator 2
>Isolator status signal Open for isolator 2
>Isolator status signal Closed for isolator 3
>Isolator status signal Open for isolator 3
>Isolator status signal Closed for isolator 4
>Isolator status signal Open for isolator 4
>Isolator status signal Closed for isolator 5
>Isolator status signal Open for isolator 5
>Breaker failure protection initiation for phase L1
>Breaker failure protection initiation for phase L2
>Breaker failure protection initiation for phase L3
>Breaker failure protection initiation via pulse
>Breaker failure protection release signal
>Trip command release
>Bus coupler circuit breaker in Open status
>Circuit breaker disturbed
>Control bay out of service
Busbar protection common start
Busbar protection trip command L123
Breaker failure protection trip command L123
Breaker failure protection trip command L1
Breaker failure protection trip command L2
Breaker failure protection trip command L3
Circuit breaker test phase L1
Circuit breaker test phase L2
Circuit breaker test phase L3
Busbar protection transfer trip signal
Bay out of service
