Appendix
A
⋅ !
A.1.8 Reference table for configuration parameters - bay unit
6000 MARSHALLING
6100 MARSHALLING BINARY INPUTS
pre–settings:
6101 BINARY INPUT 1 >isolator 1 closed A 1)
6102 BINARY INPUT 2 >isolator 1 open A
6103 BINARY INPUT 3 >isolator 2 closed A
6104 BINARY INPUT 4 >isolator 2 open A
6105 BINARY INPUT 5 >isolator 3 closed A
6106 BINARY INPUT 6 >isolator 3 open A
6107 BINARY INPUT 7 >isolator 4 closed A
6108 BINARY INPUT 8 >isolator 4 open A
6109 BINARY INPUT 9 >isolator 5 closed A
6110 BINARY INPUT 10 >isolator 5 open A
6111 BINARY INPUT 11 >CBF L1 A
6112 BINARY INPUT 12 >CBF L2 A
6113 BINARY INPUT 13 >CBF L3 A
6114 BINARY INPUT 14 >CB CLOSE com A
6115 BINARY INPUT 15 >CBF rel A
6116 BINARY INPUT 16 >CB test A
6117 BINARY INPUT 17 >CB open A
6118 BINARY INPUT 18 not marshalled
6119 BINARY INPUT 19 >CB fail A
6120 BINARY INPUT 20 >Bay o.of ser A
6200 MARSHALLING SIGNAL RELAYS
6201 SIGNAL RELAY 1 pre–setting: Bay o.of ser nm 2)
6300 MARSHALLING LED INDICATORS
pre–setting:
6301 LED 1 (red) >Isolator 1 closed nm 2)
6302 LED 2 (green) >Isolator 1 open nm
6303 LED 3 (red) >Isolator 2 closed nm
6304 LED 4 (green) >Isolator 2 open nm
6305 LED 5 (red) >Isolator 3 closed nm
6306 LED 6 (green) >Isolator 3 open nm
6307 LED 7 (red) >Isolator 4 closed nm
6308 LED 8 (green) >Isolator 4 open nm
6309 LED 9 (red) >Isolator 5 closed nm
6310 LED 10 (green) >Isolator 5 open nm
6311 LED 11 (red) not marshalled
6312 LED 12 (red) not marshalled
