Common parameters
6000 CHANGE SETTINGS ?
6100 SETTINGS: BB–Diff.Protec ?
6101 STAB FAC:BZ =.65 (min. 0.10 – max. 0.80)
6102 I>DIFF. :BZ =1.00 I/Ino
1)
(min. 0.20 – max. 4.00)
6103 STAB FAC:CZ =.50 (min. 0.00 – max. 0.80)
6104 I>DIFF. :CZ =1.00 I/Ino (min. 0.20 – max. 4.00)
6105 NORM BAS IN =1000.0 A
2)
(min. 20.00 – max. 3000.00)
6106 TRIP EXTEND =.10 s (min. 0.02 – max. 1.00)
6107 BI TRIPENAB =not existent (non existent, existent)
6108 T–CB OPEN =0 s (min. 0.00 – max. 1.00)
6200 SETTINGS: Bkr.Fail Protec?
6201 BF BI MODE =1–chanelWithSup (1–chanel no sup, 1–chanelWithSup,
2–chanel no Sup, 2–chanelWithSup)
6202 STAB FAC:BF =.50 (min. 0.00 – max. 0.80)
6203 I>DIFF. :BF =2*I>BF (DA 6700)
3)
6204 TIME UNB BF =.25 s (min. 0.05 – max. 1.00)
6205 T–BF IMPULS =.50 s (min. 0.05 – max. 1.00)
6206 T–CB FAULT =.10 s (min. 0.00 – max. 1.00)
6207 TR REPOPMOD =single–phase (single–phase, three–phase)
6208 T–TRIP REP =.12 s (min. 0.00 – max. 1.00)
_______________
 Ino – Normalized nominal current related to base current transformer
(current transformer with highest transformation ratio)
 Nominal current of the base current trans-
former
 DA 67XY with XY = bay number 01 to 48
