6.3.2 Prerequisite and language for operation
The request to enter the password appears automatiĆ
cally as soon as the operating tree enters branches
which require a password (e.g. modification mode
with parameterizing and configuration, execution of
test functions. The input of the password is terminaĆ
ted by the ENTER-key. Keys F1 to F4 may be used
for the password.
User password:
Sequence of keys:
F3-F1-F3-F1-F3-F1
No password is required for reading out operational
data, alarms and settings.
E N T E R C O D E W O R D :
@ @ @ @ @ @
C W A C C E P T E D
The entered characters do not appear in the display.
Instead each one @ is displayed. After confirmation of
the input by "ENTER", the display shows CW ACCEPĆ
TED with the correct password.
C O D E W O R D W R O N G
If the code was wrong, then CODEWORD WRONG
is displayed. The password may be entered again
after twice depressing the key ENTER .
If the password was accepted, then the parameteriĆ
zing may start. In the following, each operating adĆ
dress will be shown in a box and will be explained.
The communication language can be selected via diĆ
rect address DA 7101/FE. Optionally German or EnĆ
glish may be chosen.
Fig 6.1 shows an overview for the operating tree of
the bay unit. Selected settings and configuration funcĆ
tions can be changed by calling up blocks
1100 Network data
6000 Marshalling of binary inputs and outputs
7100 Integrated operation
Test and control functions are available under the
block address
4000 Tests.
Change of settings and executing control functions
require entering of the user password.
Operational measured values can be displayed under
block adress 5700.
5700 Operational measured values
