A - 4
Siemens AG ⋅ May 1998
Table A.9.1 Alarms from the master unit for PC, LC display and binary inputs and outputs
FNo Event
buffer
Logical function Short text
(text on LC display)
SM-No Relay/
LED-
no.
Alarm
characteĆ
ristic
0 OE Failure with protection blocking Err. PROT BLOCK - 1, M C/G
1OEFailure without protection blocking Err. PROT ACTIVE - 2, M C/G
2
3OESystem initialise REBOOT - 1) C
4OEReset of system processors DEVICE RESTART - 1) C
5OEVoltage failure VOLTAGE FAIL - 1) C
6OEReset after configuration RESTART AFT CONF - 1) C
7OESettings being set Setting - 1) C/G
8OEConfiguration being set Configuration - 1) C/G
9OEFault: CBF-BI L1 time exceeded or
Fault: CBF-BI release outside time
window
BF BI err:L1:BXY - 12, M C/G+BN
10 OE Fault: CBF-BI L2 time exceeded or
Fault: CBF-BI release outside time
window
BF BI err:L2:BXY - 12, M C/G+BN
11 OE Fault: CBF-BI L3 time exceeded or
Fault: CBF-BI release outside time
window
BF BI err:L3:BXY - 12, M C/G+BN
12 OE Fault: CBF-BI release
time exceeded
BF COM BIN MON T - 12, M C/G
13 OE LED-reset LED-reset - - C
14 FE Missing TRIP-command release no TripReleas:BXY - 30, M C+BN
15 OE Bay out of service out of serv.:BXY - 11 C/G+BN
16 FE Trip command for bus zone 01 L1 TRP BZ01 L1= zzz 30 17, M C+FN
17 FE Trip command for bus zone 02 L1 TRP BZ02 L1= zzz 30 18, M C+FN
18 FE Trip command for bus zone 03 L1 TRP BZ03 L1= zzz 30 19, M C+FN
19 FE Trip command for bus zone 04 L1 TRP BZ04 L1= zzz 30 20, M C+FN
20 FE Trip command for bus zone 05 L1 TRP BZ05 L1= zzz 30 21, M C+FN
21 FE Trip command for bus zone 06 L1 TRP BZ06 L1= zzz 30 22, M C+FN
22 FE Trip command for bus zone 07 L1 TRP BZ07 L1= zzz 30 23, M C+FN
23 FE Trip command for bus zone 08 L1 TRP BZ08 L1= zzz 30 24, M C+FN
24 FE Trip command for bus zone 09 L1 TRP BZ09 L1= zzz 30 25, M C+FN
25 FE Trip command for bus zone 10 L1 TRP BZ10 L1= zzz 30 26, M C+FN
26 FE Trip command for bus zone 11 L1 TRP BZ11 L1= zzz 30 27, M C+FN
27 FE Trip command for bus zone 12 L1 TRP BZ12 L1= zzz 30 28, M C+FN
28 FE Trip Repetition L1 Trip Rep.L1:BXY - 14, M C+BN
29 FE Breaker failure/transfer trip transf Trp:BXY - 15, M C+BN
30 FE Trip Group alarm "fast trip-command" no alarm text - 16, M
31
