 '(& )( )'& &) ( &!&  ")& &$(( $#   Ć %&( $# #)" &&#$ 
 

6 - 44
Siemens AG ⋅ May 1998
Table 6.12 Pre-set command relay functions
Direct
adress
1st display line 2nd display line FNo Note
6400
6401
6402
6403
6404
6405
MARSHALLING
COMMAND RELAY 1
COMMAND RELAY 2
COMMAND RELAY 3
COMMAND RELAY 4
COMMAND RELAY 5
COMMAND RELAY
CBF TRIP L1
BBP TRIP L123
CBF TRIP L123
CB test TRIP L1
CBF TRIP L2
BBP TRIP L123
CBF TRIP L123
CB test TRIP L2
CBF TRIP L3
BBP TRIP L123
CBF TRIP L123
CB test TRIP L3
BBP TRIP L123
CBF TRIP L123
CBF TRIP L1
CBF TRIP L2
CBF TRIP L3
CB test TRIP L1
CB test TRIP L2
CB test TRIP L3
BBP TRANSF TRIP
7051
7040
7050
7060
7052
7040
7050
7061
7053
7040
7050
7062
7040
7050
7051
7052
7053
7060
7061
7062
7070
Breaker failure protection trip command L1
Busbar protection trip command L123
Breaker failure protection trip command L123
Circuit breaker test phase L1
Breaker failure protection trip command L2
Busbar protection trip command L123
Breaker failure protection trip command L123
Circuit breaker test phase L2
Breaker failure protection trip command L3
Busbar protection trip command L123
Breaker failure protection trip command L123
Circuit breaker test phase L3
Busbar protection trip command L123
Breaker failure protection trip command L123
Breaker failure protection trip command L1
Breaker failure protection trip command L2
Breaker failure protection trip command L3
Circuit breaker test phase L1
Circuit breaker test phase L2
Circuit breaker test phase L3
Busbar protection transfer trip command
6.4.2.6 Setting of function parameters -
block 11
Setting of the operation parameters requires passĆ
word input (refer to chapter 6.3.2). The settings can
be displayed without password, but not altered.
After the password is accepted, parameterizing can
be started.
As a commissioning support, the current transformer
starpoint can also be changed locally in the bay unit in
parallel to the setting in the master unit
(DA xx05/ZE).
Y
B
1 0 0 0 J
P A R A M E T E R S
Y
B
1 1 0 0 J
P O W E R S Y S T E M D A T A
Start of the block "power system data"
"
A
1 1 0 1 J C T S T A R P N T
T O W A R D S L I N E
Setting for the current transformer polarity
D towards line
D towards bus
