'(& )( )'& &) ( &!& ")& &$(( $# Ć %&( $# #)" &&#$
6 - 47
Siemens AG ⋅ May 1998
"
A
5 7 0 3 J M E A S . V A L U E
I L 3 [ % ] = 1 0 1 . 5 %
Current of phase L3
"
A
5 7 0 4 J M E A S . V A L U E
I E [ % ] = 1 . 1 %
Earth current
"
A
5 7 0 5 J M E A S . V A L U E
I D L 1 [ % ] = 0 . 1 %
Phase-related operational measured value of the difĆ
ferential current. Display in percent.
The differential current display for phases L2 and L3
follow under direct addresses and
.
"
A
5 7 0 8 J M E A S . V A L U E
I S L 1 [ % ] = 0 . 1 %
Phase-related operational measured value of the staĆ
bilizing current of the check zone.
The stabilizing currents for phases L2 and L3 are disĆ
played after selecting addresses and
.
"
A
5 7 1 1 J M E A S . V A L U E
f [ H z ] = 5 0 . 1 H z
Nominal frequency in Hertz.
I L 1 [ % ] = 1 0 0 . 1 %
I L 2 [ % ] = 1 0 0 . 3 %
I L 3 [ % ] = 1 0 1 . 0 %
I E [ % ] = 1 . 0 %
Example for the "4-line mode"
The display is requested by the pushbutton LED or
from the initial display ( ) by depressing
key "ENTER".
Selection of the measured values for display is done
in adress block 71 (refer to chapter 6.4.1).
I L 1 = 1 0 0 0 . 3 A
I L 2 = 1 0 0 1 . 5 A
I D L 1 [ % ] = 1 0 . 1 %
I S L 1 [ % ] = 1 0 2 . 5 %
Example for display of absolute and percentage vaĆ
lues.
