A - 10
Siemens AG ⋅ May 1998
FNo Alarm
characteĆ
ristic
Relay/
LED-
no.
SM-NoShort text
(text on LC display)
Logical functionEvent
buffer
192 OE Measured value supv. I-SUM MEAS in sup:BXY 1 M C/G+BN
193 OE 15V supply supervision FE 15V-superv.:BXY 1 10, M C/G+BN
195 OE 0V supply supervision FE 0V-superv.:BXY 1 10, M C/G+BN
196 OE Failure in auto. testing: BSZ 1 L1 FLT AUT L1 -1:BXY 0/1
5)
1) C+BN
197 OE Failure in auto. testing: BSZ 2 L1 FLT AUT L1 -2:BXY 0/1
5)
1) C+BN
198 OE Failure in auto. testing: BSZ 3 L1 FLT AUT L1 -3:BXY 0/1
5)
1) C+BN
199 OE Failure in auto. testing: BSZ 1 L2 FLT AUT L2 -1:BXY 0/1
5)
1) C+BN
200 OE Failure in auto. testing: BSZ 2 L2 FLT AUT L2 -2:BXY 0/1
5)
1) C+BN
201 OE Failure in auto. testing: BSZ 3 L2 FLT AUT L2 -3:BXY 0/1
5)
1) C+BN
202 OE Failure in auto. testing: BSZ 1 L3 FLT AUT L3 -1:BXY 0/1
5)
1) C+BN
203 OE Failure in auto. testing: BSZ 2 L3 FLT AUT L3 -2:BXY 0/1
5)
1) C+BN
204 OE Failure in auto. testing: BSZ 3 L3 FLT AUT L3 -3:BXY 0/1
5)
1) C+BN
205 OE Failure in auto. testing:
(com. alarm)
no alarm text 0/1
5)
5, M-
206 OE 15V-supervision CU 15V-superv. CU 1 10, M C/G
207 OE 24V-supervision CU 24V-superv. CU 1 10, M C/G
208 OE Request restart req restart 215 1) C+BN
209 OE Request change CT Polarity RqChangCTPol: BXY 215 1) C+BN
210 OE Request bay out of service request BOS: BXY 215 1) C/G+BN
211 OE Request manual trip L1 req man Trp L1:BXY 215 1) C+BN
212 OE Request manual trip L2 req man Trp L2:BXY 215 1) C+BN
213 OE Request manual trip L3 req man Trp L3:BXY 215 1) C+BN
214 OE Request manual trip L1 L2 L3 req man T L123:BXY 215 1) C+BN
215 OE Request bay (Group alarm for rel.) no alarm text - 29, M-
216
217
218
219
220
221
222
223
