A - 15
Siemens AG ⋅ May 1998
Table A.9.2 Basic position of jumpers on ZPS-module (master unit)
ZPS-module
Jumper SBK BSZ 1 BSZ 2 BSZ 3 SK 1 SK 2 SK 3 SK 4 SK 5 SK 6
X20 off off off off off off off off off off
X22 off off off off off off off off off off
X23 on on on on on on on on on on
X24 off off off off off off off off off off
X25 5 - 6 off off off off off off off off off
X26 off 5-6 5-6 5-6 5-6 5-6 5-6 5-6 5-6 5-6
X27 on on on on on on on on on on
X29 on off off off off off off off off off
X30 off on off off off off off off off off
X31 off off off off off off off off off off
X32 on on on on on on on on on on
X33 off off off off off off off off off off
X34 on off off off off off off off off off
Table A.9.3 Basic position of switches on ZPS-module (master unit)
ZPS-function
Switch SBK
1)
BSZ 1 BSZ 2 BSZ 3 SK 1 SK 2 SK 3 SK 4 SK 5 SK 6
S2
S2.1 off off off off off off off off off off
S2.2 off off off off off off off off off off
S2.3 off off off off off off off off off off
S2.4 off on on on on on on on on on
S2.5 off off off off off off off off off off
S2.6 off off off off off off off off off off
S3
S3.1 off on on on on on on on on on
S3.2 off off on off on off on off on off
S3.3 off on on off off on on off off on
S3.4 off off off on on on on off off off
S3.5 off off off off off off off on on on
S3.6 off on on on on on on on on on
1) position not relevant
