3 - 4
Siemens AG ⋅ May 1998
Table 3.2 Electrical tests (continued)
IEC 255-6, IEC 255-22
(international product standards)
EN 50082-2 (technical generic stanĆ
dards)
DIN VDE 0435 part 303 (German proĆ
duct standards for protection deviĆ
ces)
High-energy pulse/surge
EN 61000-4-5; EN 50082-2;
IEC 1000-4-5; auxiliary voltage input DC/signal lines:
class III
HF on lines
IEC 1000-4-6; VDE 0843 part 6;
EN 61000-4-6; class III
Magnetic field with energy-technical frequency
IEC 1000-4-8; IEC 255-6; EN 60255-6;
EN 61000-4-8; VDE 0847 part 4-8; class IV
Auxiliary voltage inputs/signal lines
1 kV sym./2 kV unsym.
5 pulses, both polarities
10 V (r.m.s. value); 150 kHz to
80 MHz; 80 %; 1 kHz; AM;
l
= 150
30 A/m ; continuously;
300 A/m for 3 s; 50 Hz; 0,5 mT
Table 3.3 Mechanical tests
IEC 255-21-1, class II;
IEC 68-2-6, test Fc
permissible mechanical impact
in service (severity 12 acc. to SN 29010 T.2)
during transport (severity 23 acc. to SN 29010 T.2)
sinusoidal
10 to 60 Hz,
"0,075 mm amplitude;
60 to 150 Hz; 1 acceleration; freĆ
quency spectrum 1 oktave/min;
20 cycles in 3 axes rectangular to
one another
sinusoidal
5to8Hz;
"7,5 mm amplitude;
8 to 150 Hz; 2 acceleration; freĆ
quency spectrum 1 oktave/min;
20 cycles in 3 axes rectangular to
one another
Table 3.4
EN 60255-6
IEC 255-6
DIN VDE 0435 Teil 303
permissible ambient temperature
in operation
for storage
during transport
during start-up
Humidity in operation
-10 to +55 °C (bay unit)
0to+55°C (master unit)
-25 to +70 °C
-25 to +70 °C
-10 to +55 °C (bay unit)
0to+55°C (master unit)
annual average
v75 % relative huĆ
midity, on 30 days per year up to
95 % relative humidity, no condenĆ
sation permitted
The devices should be assembled such that they are not imposed to direct solar radiation or abrubt change in temperature which
might cause condensation.
Commissioning at temperatures v0 _C is permissible only if the site conditions ensure that no command output can be activated
unless the device temperature has reached 0 _C.
