3RV1 circuit breaker
SIRIUS System Manual
GWA 4NEB 430 0999-02b
2-65
2.7.3 Limiter function with standard devices for 500 VAC and 690 VAC in acc. with IEC 60 947-2
The table lists the rated limit short-circuit breaking capacity
I
cu
and the rated service short-circuit breaking capacity
I
cs
with an
upstream standard circuit breaker that fulfills the limiter function at 500 VAC and 690 VAC.
The short-circuit breaking capacity can be significantly increased using the upstream standard circuit breaker with a limiter function.
The circuit-breaker connected downstream, should be set to the rated current of the load. Be sure when you set up circuit breaker
combinations to note to the distances between the grounded parts and the distances between the circuit breakers.
Make sure that the cabling between the circuit breakers is short circuit-proof. You can set up the circuit breakers side by side.
No upstream circuit breaker required because it is short circuit-proof up to 100 kA
1)10% overvoltage
2)5% overvoltage
Characteristics
You can obtain the characteristics for all the setting ranges from our Techni-
cal Assistance team by e-mail: (
nst.technical-assistance@siemens.de)
.
Standard circuit breaker
with limiter function
Standard circuit breaker
To 5 0 0 VA C
1
)/
525 V
2
)
To 690 VAC
1
)
Type Rated current
I
n
I
cu
I
cs
I
cu
I
cs
Rated current
I
n
Type A kAkAkAkA
3RV13 21-4DC10 3RV10 2
To 1
Frame size S0 Frame size S0 1.25
I
n
= 25 A 1.6
25025
2.5 50 25
3.2 50 25
45025
55025
6.3 50 25
8 100 50 20 10
10 100502010
12.5 100502010
16 100502010
20 100502010
22 100502010
25 100502010
3RV13 31-4HC10 3RV10 3
16 100505025
Frame size S2 Frame size S2 20 100 50 50 25
I
n
= 50 A 25 100 50 50 25
32 100505025
40 100505025
50 100505025
3RV13 41-4HC10 3RV10 4
32 100505025
Frame size S3 Frame size S3 40 100 50 50 25
I
n
= 50 A 50 100 50 50 25
3RV13 41-4MC10 3RV10 4
50 100505025
Frame size S3 Frame size S3 63 100 50 50 25
I
n
= 100 A 75 100 50 50 25
90 100505025
100 100 50 50 25
