Siemens SIRIUS System Manual

System overview
SIRIUS System Manual
GWA 4NEB 430 0999-02b
1-15
1.5 Mounting methods and terminal systems
1.5.1 Mounting the equipment
The method of mounting the equipment is uniform within each frame size.
Table 1-2: Mounting methods
Screw-on mounting
The SIRIUS switching devices can be screwed on to a flat surface.
Please note the following points with some of the devices:
• 3RV1 circuit breaker, frame sizes S00/S0: Push-in lugs are required for
screw-type mounting
• 3RP15 time relay: Push-in lugs are required for screw-type mounting
• Coupling links: No screw-type mounting
• Soft starters: No screw-type mounting
Snap-on mounting
The SIRIUS switching devices are snapped onto 35 mm rails in acc. with
DIN EN 50 022 without a tool.
The devices with a frame size of S3 require a rail with an installation height
of 15 mm. Alternatively, they can also be snapped onto 75 mm rails.
Frame size Mounting Removal
S00 to S3 Screwed on Removed with a screwdriver
S00, S0 Snapped onto a
35 mm rail (in acc. with
DINEN50022)
Removed without a tool
S2 Snapped onto a
35 mm rail (in acc. with
DINEN50022)
The snap-on spring can be opened with a
screwdriver
S3 Snapped onto a
35 mm rail (in acc. with
DINEN50022)
Snapped onto a
75 mm rail
The snap-on spring can be opened with a
screwdriver

Siemens SIRIUS Specifications

General

Product brand name	Siemens
Series	SIRIUS
Coil Voltage	24V DC, 110V AC, 230V AC
Switching Capacity	Up to 10A
Mounting Type	DIN rail
Product designation	SIRIUS
Contact Material	Silver alloy
Contact Rating	Varies depending on the specific SIRIUS relay model (e.g., 6 A at 250 V AC, 10 A at 250 V AC)
Switching Voltage	Varies depending on the specific SIRIUS relay model (e.g., 250 V AC, 400 V AC)
Mechanical Life	Up to 10 million operations
Electrical Life	Up to 100, 000 operations
Operating Temperature	-25°C to +55°C
Protection Class	IP20
Size of relay base	Varies depending on the specific SIRIUS relay model
