Page #357 background imageLoading...
Page #357 background image
3RP10, 3RP15 solid-state time relays
SIRIUS System Manual
GWA 4NEB 430 0999-02b
7-13
Identifying letters
The following table lists the identifying letters for the 8 or 16 functions of
the solid-state multifunctional 3RP15 05 time relay:
The
after the identifying letter indicates that the second changeover con-
tact present reacts as an immediate switching contact (controlled by the
supply voltage or the start contact depending on the function). If this
is not
present, the second changeover contact reacts with a time delay like the
first changeover contact.
Function
Identifying letter
with time relay
with 1
changeover
contact
Identifying letter
with time relay
with 2
changeover
contacts
On-delay A A
Off-delay with auxiliary supply B B
On-delay and off-delay with auxiliary supply C C
Flashing, start with break D D
Making pulse contact E E
Breaking pulse contact with auxiliary supply F F
Shaping pulse contact with auxiliary supply G G
Additive on-delay with auxiliary supply (and
immediate switching only H
)
HH
On-delay and immediate switching A
Off-delay with auxiliary supply B
On-delay and off-delay with auxiliary supply
and immediate switching
C
Flashing, start with break, and immediate
switching
D
Making pulse contact and immediate switch-
ing
E
Breaking pulse contact with auxiliary supply
and immediate switching
F
Shaping pulse contact with auxiliary supply
and immediate switching
G
Star-delta function
*d
Table 7-4: 3RP15 05 (multifunctional) assignment of the identifying letters
