3RH, 3TX, LZX coupling links
SIRIUS System Manual
6-2
GWA 4NEB 430 0999-02b
6.1 Specifications/regulations
Table 6-1: Regulations and specifications
Degrees of protection
offered by housing
EN 60 529
I/O interfaces EN 61 131-2
Connection designations EN 50 005
DIN standard rail EN 50 022
Coordination of insula-
tion
VDE 0110
Electrical relays,
all-or-nothing relays
DIN VDE 0435 Part 201/IEC 60255-1-00
Control devices
and switching elements
DIN VDE 0660 Part 200/IEC 60947-5-1
Optocoupler DIN VDE 0884
Equipment of
high-voltage installations
DIN VDE 0160
Shock protection DIN VDE 0106 Part 100
Safe isolation DIN VDE 0106 Part 101
Environmental conditions IEC 60721
EMC
emission
immunity
EN 50081
EN 50082
General information VDE 0660 Part 100/IEC 60947-1
Specifications for indus-
trial control systems
UL 508
Specifications for indus-
trial equipment
CSA C22.2-14
