Siemens SIRIUS System Manual

3RT1/3RH1 contactors
SIRIUS System Manual
3-112
GWA 4NEB 430 0999-02b
1)Corresponds to section from IEC 60 947-4 (VDE 0660 Part 102):
Coordination type "1": Coordination type "2"
The destruction of the contactor and the overload relay is permissible. The overload relay must not be damaged.
The contactor and/or overload relay must be replaced, if necessary. Contact welding on the contactor is permissible, if it can be easily
separated again from the contactor.
2)Test conditions in acc. with IEC 60 947-4-1
3)Resistance-heated industrial furnaces and electric heating appliances, etc. (increased current consumption at startup of heating taken into account).
3RT1 contactors for switching motors
Contactor
Frame size
Type
S00
3 RT1.1.
Auxiliary circuit
Fuse-links, performance class gL/gG A 10
DIAZED type 5SB, NEOZED type 5SE (unwelded fuse at
I
k
≥
1 kA)
Or miniature circuit breaker (up to 230 V) with C characteristic
(short-circuit current
I
k
< 400 A)
A6
Contactor
Frame size
Type
S00
3 RT1.1.
Drive
Operating range of the magnet coils
AC At 50 Hz: 0.8 to 1.1 x
U
s
At 60 Hz: 0.85 to 1.1 x
U
s
DC At +50 °C: 0.8 to 1.1 x
U
s
At +60 °C: 0.85 to 1.1 x
U
s
Power input of the magnet coils
(cold coil and at 1.0 x
U
s
)
Standard version For USA and Canada
AC operation Hz 50/60 50 60
Making capacity
cos
ϕ
Holding power
cos
ϕ
VA
VA
27/24.3 26.4 31.7
0.8/0.75 0.81 0.77
4.4/3.4 4.7 5.1
0.27/0.27 0.26 0.27
DC operation Making capacity = holding power W 3.3
Contactor Frame size
Type
S00 S00 S00
3RT10 15 3RT10 16 3RT10
Main circuit
Current carrying capacity with alternating current
Utilization category AC-1, switching of resistive
loads
Rated operational currents
I
e
At 40 °C up to 690 V
At 60 °C up to 690 V
A
A
18 22 22
16 20 20
Rated power
of three-phase loads
3
)
cos
ϕ
= 0.95 (at 60 °C)
At 230 V
400 V
500 V
690 V
kW
kW
kW
kW
6 . 3 7. 5 7. 5
11 13 13
13.8 17 17
19 22 22
Minimum conductor cross-section loaded with
I
e
At 40 °C
60 °C
mm
2
mm
2
2.5 2.5 2.5
2.5
2.5 2.5
Contactor Frame size
Type
S00
3RT10 15
S00
3RT10 16
S00
3RT10 17
Main circuit
Current carrying capacity with alternating current
Utilization categories AC-2 and AC-3
Rated operational currents
I
e
To 40 0 V
500 V
690 V
A
A
A
7
5
4
9
6.5
5.2
12
9
6.3
Rated power of motors
with slipring or squirrel-cage rotor at 50 Hz and 60 Hz
230 V
kW 2.2 3 3
400 V
kW 3 4 5.5
500 V
W 3.5 4.5 5.5
690 V
kW 4 5.5 5.5
Thermal stress
10-s current
1
) A 56 72 96
Power loss per conducting path
At
I
e
/AC-3 W 0.42 0.7 1.24

Siemens SIRIUS Specifications

General

Product brand name	Siemens
Series	SIRIUS
Coil Voltage	24V DC, 110V AC, 230V AC
Switching Capacity	Up to 10A
Mounting Type	DIN rail
Product designation	SIRIUS
Contact Material	Silver alloy
Contact Rating	Varies depending on the specific SIRIUS relay model (e.g., 6 A at 250 V AC, 10 A at 250 V AC)
Switching Voltage	Varies depending on the specific SIRIUS relay model (e.g., 250 V AC, 400 V AC)
Mechanical Life	Up to 10 million operations
Electrical Life	Up to 100, 000 operations
Operating Temperature	-25°C to +55°C
Protection Class	IP20
Size of relay base	Varies depending on the specific SIRIUS relay model
