Page #222 background image
3RT1/3RH1 contactors
SIRIUS System Manual
3-114
GWA 4NEB 430 0999-02b
3RT10 2. contactors for switching motors
1)Corresponds to section from IEC 60 947-4 (VDE 0660 Part 102):
Coordination type "1":
The destruction of the contactor and the overload relay is permissible. The contactor and/or overload relay must be replaced, if necessary.
Coordination type "2":
The overload relay must not be damaged. Contact welding on the contactor is permissible, if it can be easily
separated again from the contactor.
2)Test conditions in acc. with IEC 60 947-4-1.
Unwelded 3RT11 contactors, see Chapter 5 (overload and short-circuit protection only with the 3RV10 circuit breaker).
Contactor Frame size
Type
S0
3RT10 2.
Rated insulation voltage
U
i
(pollution degree 3) V 690
Protective separation
between the coil and main contacts
(in acc. with DIN VDE 0106 Part 101 and A1 [Draft 2/89])
V400
Permissible ambient temperature
For operation
During storage
°C
°C
–25 to +60
–55 to +80
Degree of protection
in acc. with IEC 60 947-1 and DIN 40 050 IP 20, actuating system IP 20
Shock resistance
Rectangular impulse AC operation
g
/ms 8.2/5 and 4.9/10
DC operation
g
/ms 10/5 and 7.5/10
Sine pulse AC operation
g
/ms 12.5/5 and 7.8/10
DC operation
g
/ms 15/5 and 10/10
Short-circuit protection for contactors without overload relay
Short-circuit protection for contactors with overload relay, see Chapter 4.
Short-circuit protection for unwelded contactors, see Chapter 5
(overload and short-circuit protection only with the 3RV10 circuit breaker).
Short-circuit protection for fuseless load feeders, see Chapter 5.
Contactor Frame size
Type
S0
3RT10 23, 3RT10 24
S0
3RT10 25
S0
3RT10 26
Main circuit
Fuse-links, performance class gL/gG
NH type 3NA, DIAZED type 5SB, NEOZED type 5SE
With fuse-links
– In acc. with IEC 60 947-4/DIN EN 60 947-4
(VDE 0660 Part 102)
Coord. type "1"
1
) A 63 63 100
Coord. type "2"
1
) A 25 25 35
Unwelded
2
) A 10 10 16
Or miniature circuit breaker with C characteristic A 25 25 32
(Short-circuit current 3 kA, coordination type 1)
1
)
Auxiliary circuit
Fuse-links, performance class gL/gG A 10 10 10
DIAZED type 5SB, NEOZED type 5SE
(unwelded fuse at
I
k
1 kA)
Or miniature circuit breaker with C characteristic (short-circuit current
I
k
< 400 A) A 10 10 10
Contactor Frame size
Type
S0
3RT10 2.
Drive
Operating range of the magnet coils
AC/DC 0.8 to 1.1 x
U
s
Power input of the magnet coils
(cold coil and at 1.0 x
U
s
)
Standard version For USA and Canada
AC operation Hz 50 50/60 50 60
Making capacity
cos
ϕ
Holding power
cos
ϕ
VA
VA
61 64 /63 61 69
0.82 0.72/ 0.74 0.82 0.76
7.8 8.4 / 6.8 7.8 7.5
0.24 0.24/ 0.28 0.24 0.28
DC operation making capacity = holding power W 5.4
