Siemens SIRIUS System Manual

3RT1/3RH1 contactors
SIRIUS System Manual
GWA 4NEB 430 0999-02b
3-117
1)Corresponds to section from IEC 60 947-4 (VDE 0660 Part 102):
Coordination type "1":
The destruction of the contactor and the overload relay is permissible. The contactor and/or overload relay must be replaced, if necessary.
Coordination type "2":
The overload relay must not be damaged. Contact welding on the contactor is permissible, if it can be easily
separated again from the contactor.
2)Test conditions in acc. with IEC 60 947-4-1.
Unwelded 3RT11 contactors, see Chapter 5 (overload and short-circuit protection only with the 3RV10 circuit breaker).
2) Resistance-heated industrial furnaces and electric heating appliances, etc. (increased current consumption at startup of heating taken into account).
3RT10 3. contactors for switching motors
Contactor Frame size
Type
S2
3RT10 34
S2
3RT10 35
S2
3RT10 36
Auxiliary circuit
Fuse applications, performance class gL/gG A 10 10 10
DIAZED type 5SB, NEOZED type 5SE
(unwelded fuse at
I
k
≥
1 kA)
Or miniature circuit breaker with C characteristic
(short-circuit current
I
k
< 400 A)
A101010
Contactor Frame size
Type
S2
3RT10 34
S2
3RT10 35
S2
3RT10 36
Drive
Operating range of the magnet coils
AC/DC 0.8 to 1.1 x
U
s
Power input of the magnet coils
(cold coil and at 1.0 x
U
s
)
Standard version
AC operation Hz 50 50/60 50 50/60
Making capacity
cos
ϕ
Holding power
cos
ϕ
VA
VA
104 127 /113
0.78 0.73/ 0.69
9.7 11.3 / 9.5
0.42 0.41/ 0.42
145 170 /155
0.79 0.76/ 0.72
12.5 15 / 11.8
0.36 0.35/ 0.38
For USA and Canada
Hz 50 60 50 60 50 60
Making capacity
cos
ϕ
Holding power
cos
ϕ
VA
VA
90 118
0.76 0.8
11 12
0.38 0.41
160 127
0.82 0.85
13.5 14.2
0.34 0.37
160 127
0.82 0.85
13.5 14.2
0.34 0.37
DC operation making capacity = holding power W 13.3 13.3 13.3
Main circuit
Current carrying capacity with alternating current
Utilization category AC-1, switching of resistive
loads
Rated operational currents
I
e
At 40 °C up to 690 V
At 60 °C up to 690 V
A
A
50
45
60
55
55
50
Rated power
of three-phase loads
2
)
cos
ϕ
= 0.95 (at 60 °C)
At 230 V
400 V
500 V
690 V
kW
kW
kW
kW
18
31
39
54
22
38
46
66
20
35
43
60
Minimum conductor cross-section loaded with
I
e
At 40 °C
60 °C
mm
2
mm
2
16
10
16
16
16
10

Siemens SIRIUS Specifications

General

Product brand name	Siemens
Series	SIRIUS
Coil Voltage	24V DC, 110V AC, 230V AC
Switching Capacity	Up to 10A
Mounting Type	DIN rail
Product designation	SIRIUS
Contact Material	Silver alloy
Contact Rating	Varies depending on the specific SIRIUS relay model (e.g., 6 A at 250 V AC, 10 A at 250 V AC)
Switching Voltage	Varies depending on the specific SIRIUS relay model (e.g., 250 V AC, 400 V AC)
Mechanical Life	Up to 10 million operations
Electrical Life	Up to 100, 000 operations
Operating Temperature	-25°C to +55°C
Protection Class	IP20
Size of relay base	Varies depending on the specific SIRIUS relay model
