3RT10 4. contactors for switching motors
1)Corresponds to section from IEC 60 947-4 (VDE 0660 Part 102):
Coordination type "1":
The destruction of the contactor and the overload relay is permissible. The contactor and/or overload relay must be replaced, if necessary.
Coordination type "2":
The overload relay must not be damaged. Contact welding on the contactor is permissible, if it can be easily
separated again from the contactor.
2)Test conditions in acc. with IEC 60 947-4-1
Contactor Frame size
Type
S3
3RT10 4.
Mechanical
life
Basic units
Basic unit with attached auxiliary switch block
Electronically optimized auxiliary switch block
Opera-
ting
cycles
10 mill.
10 mill.
5 mill.
Rated insulation voltage
U
i
(pollution degree 3) V 1000
Protective separation
between the coil and main contacts
(in acc. with DIN VDE 0106 Part 101 and A1 [Draft 2/89])
V690
Permissible ambient temperature
For operation
During storage
°C
°C
–25 to +60
–55 to +80
Degree of protection
in acc. with IEC 60 947-1 and DIN 40 050 IP 20 (terminal housing IP 00), actuating system IP 40
Shock resistance
Rectangular impulse AC and DC operation
g
/ms 6.8/5 and 4/10
Sine pulse AC and DC operation
g
/ms 10.6/5 and 6.2/10
Short-circuit protection for contactors without overload relay
Short-circuit protection for contactors with overload relay, see Part 4.
Short-circuit protection for fuseless load feeders, see Chapter 5.
Contactor Frame size
Type
S3
3RT10 44
S3
3RT10 45
S3
3RT10 46
Main circuit
Fuse applications, performance class gL/gG
NH type 3NA, DIAZED type 5SB, NEOZED type 5SE
– In acc. with IEC 60 947-4/DIN EN 60 947-4
(VDE 0660 Part 102)
Coordin. type "1"
1
) A 250 250 250
Coordin. type "2"
1
)A125 160 160
Unwelded
2
)A63 100 100
Auxiliary circuit
Fuse applications, performance class gL/gG A 10 10 10
(unwelded fuse at
I
k
≥
1 kA)
DIAZED type 5SB, NEOZED type 5SE
Or miniature circuit breaker with C characteristic (short-circuit current
I
k
< 400 A) A 10 10 10
Contactor Frame size
Type
S3
3RT10 44
S3
3RT10 45
S3
3RT10 46
Drive
Operating range of the magnet coils
AC/DC 0.8 to 1.1 x
U
s
Power input of the magnet coils
(cold coil and at 1.0 x
U
s
)
Standard version
AC operation Hz 50 50/60 50 50/60 50 50/60
Making capacity
cos
ϕ
Holding power
cos
ϕ
VA
VA
218 247 /211
0.61 0.62/ 0.57
21 25 / 18
0.26 0.27/ 0.3
270 298 /274
0.68 0.7 / 0.62
22 27 / 20
0.27 0.29/ 0.31
270 298 /274
0.68 0.7 / 0.62
22 27 / 20
0.27 0.29/ 0.31
For USA and Canada
Hz 50 60 50 60 50 60
Making capacity
cos
ϕ
Holding power
cos
ϕ
VA
VA
218 232
0.61 0.55
21 20
0.26 0.28
270 300
0.68 0.52
22 21
0.27 0.29
270 300
0.68 0.52
22 21
0.27 0.29
DC operation making capacity = holding power W 15 15 15
