Simplex 4010ES IDNAC User Manual

page 33 579-1150 Rev M
4010ES IDNAC Fire Alarm System Installation Guide
5.2.2 Remote devices
Table 24: Remote power and notification devices installation instructions
PID Description
Installation
instructions
4009-9401 4009T TrueAlert Controller 574-762
4081-9306 4100U External Battery Charger 120V (With Cabinet; Holds 11 Ah Batteries) 579-268
4009-9201 4009A 120V 574-181
4009-9202CA 4009A 120V ULC-listed Model 574-181
4009-9301 4009A 240V 574-181
4009-9601
4009-9602
4009 IDNAC Repeater 579-1019
4009 Remote TrueAlert Power Supply (TPS)
4009-9813 Transponder Interface Card (TIC) 579-875
4100-5120 120V Domestic TPS 579-875
4100-5121 120V Canadian TPS 579-875
4100-5122 220-240V International TPS 579-875
Table 25: Remote display and annunciation devices installation instructions
PID Description
Installation
instructions
4100-9401 Remote InfoAlarm - Red 579-687
4100-9402 Remote InfoAlarm - Beige 579-687
4100-9421 Remote InfoAlarm (French) - Red 579-687
4100-9422 4100-9422 Remote InfoAlarm (French) - Beige 579-687
4100-9441 Remote InfoAlarm (International) - Red 579-687
4100-9442 Remote InfoAlarm (International) - Beige 579-687
4100-7401 24-Point I/O Graphic Module (Requires Mounting Cabinet) 574-348
4606-9102 4010ES RUI LCD Annunciator 579-977
5.2.3 Adjunct features
Table 26: Adjunct features
PID Description
Installation
instructions
4081-9308
4100U External Battery Charger 220/230/240V (With Cabinet. Holds 110Ah
Batteries)
579-268
4190-9021 Red Fiber Modem Expansion Cabinet with Left Port Modem – Single Mode 579-831
4190-9022 Beige Fiber Modem Exp Cabinet with Left Port Modem - Single Mode 579-831
4190-9023 Right Port Modem for Exp Cabinet – Single Mode 579-831
4190-9024 Red Fiber Modem Exp Cabinet with Left Port Modem – Multimode 579-831
4190-9025 Beige Fiber Modem Exp Cabinet with Left Port Modem - Multimode 579-831
4190-9026 Right Port Modem for Expansion Cabinet – Single Mode 579-831
2975-9234 IP Gateway External Box, Red 579-1249
2975-9235 IP Gateway External Box, Platinum 579-1249
2975-9236 IP Gateway External Box, Beige 579-1249
5.2.4 End user programming tools
Table 27: End user programming tools
PID Description
4100-0292 Custom Label Editing (USB Dongle)
4100-0295 Port Vectoring Setup and Control (USB Dongle)
4100-0296 User Group/Passcode Editing (USB Dongle)
4100-0298 Walktest Configuration Setup and Control (USB Dongle)
4100-8802 Programming Unit Software

Simplex 4010ES IDNAC Specifications

General

Battery Backup	Yes
Maximum IDNAC Current per Circuit	2.5 A
Network	Yes
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
Event History Log	1, 000 events
Signaling Line Circuits (SLCs)	1
