Simrad AP16 - 3 Installation; 3.2 Installation Checklist

Operation
20221560E 51
INFO menu and Main screen active unit
12
6
39
1
2
4
57
8
10
11
1
10
1
10
3-5 sec. time out
Main screen
INFO-menu
Note ! Whenever the INFO menu is active and the mode index is
present on an active unit, operating the PORT and STBD buttons
will immediately make the main screen reappear.
INFO menu and Main Screen, inactive unit
Next INFO page
Previous INFO page
Last shown INFO page
1
1
You can view the INFO pages without activating the unit.
