Operation
20222139A 13
After approximately 5 seconds, the following message is
displayed:
The system is now operative and
the unit that was turned on will
show the Standby mode display.
Other units in a multistation system
will display "Inactive". Control is
transferred to any single unit by
pressing its’ STBY button.
A long press (2-3 sec.) on the STBY button switches the system
OFF and during this time, the alarm will sound.
Note ! In an emergency, it is possible, on a multistation system, to turn
OFF the autopilot system at any control unit by pressing the
STBY button for 2-3 seconds.
STBY mode is the mode that is used when steering the boat at
the helm.
Display information:
− Standby mode
− Current heading 345°
− Rudder angle 1° to starboard.
Note !
Whenever you take manual
control of the steering by means
of the helm irrespective of the
autopilot mode, the autopilot will
go to Standby. The “S” in the
display is replaced by a dash to
indicate that steering is from the
helm.
Flashing course knob icon
When the course knob and the PORT/STBD buttons are used
for settings etc., an icon will flash on the screen to tell that no
course changes can be made unless you press the AUTO button.
