Simrad AP25 Instruction Manual

Simrad AP25 Autopilot
14 20222139A
Alarms
In the event there is an audible alarm with explaining text on the
control unit, refer to section 6, Trouble shooting.
2.3 Follow-Up steering (FU)
In the Follow-Up steering mode the course knob may be used to
set rudder commands. The commanded rudder is shown as a
baragraph on the display and the rudder will move to a
corresponding angle and stop.
Press both
buttons
simultaneously
to activate
Follow-Up
Use course
knob to
command
rudder
Return to manual control in Standby by pressing the STBY
button
2.4 Non-Follow-Up steering (NFU)
In Standby mode, the NFU display is presented when the PORT
or STBD button is pressed. The rudder will move as long as the
button is pressed and the rudder angle is shown on the display.
Activates
PORT rudder
command
Activates
STBD
rudder
command
