Simrad AP26 - RC36 Rate Compass

Simrad AP26 and AP27 Autopilots
108 20222147A
8.5 RC36 Rate compass
Dimensions:............................... See Figure 8-4
Weight: ...................................... 0,9 kg (2,0 lbs)
Supply and interface:................. Robnet2
Power consumption:.................. 0,9 watts
Automatic Performance:
Calibration: ....................... Automatically activated by control head
Gain compensation: .......... Automatically adjusted continuously
Rate sensor stabilized heading output
Accuracy:................................... <1.25° (rms)
Repeatability:............................. <0.2° (rms)
Roll/Pitch:.................................. ± 35 degrees
Cable supplied:.......................... 15 m TP shielded Robnet2 cable
Temperature range:
Operation: ......................... 0 to +55 °C (+32 to + 130 °F)
Storage:............................. –30 to +80 °C (–22 to +176 °F)
Environmental Protection:......... IP56
Mounting: .................................. Deck or bulkhead
Material:..................................... White ABS
Figure 8-4 RC36 Rate Compass - Dimensions
