Alarms
Alarm system
The system continuously checks for dangerous situations and
system faults while the system is running. When an alarm situation
occurs, an alarm message pops up on the screen.
If you have enabled the siren, the alarm message is followed by an
audible alarm, and the switch for external alarm becomes active.
The alarm is recorded in the alarm listing so that you can see the
details and take the appropriate corrective action.
Type of messages
The messages are classified according to how the reported situation
affects your vessel. The following color codes are used:
Color Importance
Red Critical
Orange Important
Yellow Standard
Blue Warning
Green Light warning
Single alarms
A single alarm is displayed with the name of the alarm as the title,
and with details for the alarm.
Multiple alarms
If more than one alarm is activated simultaneously, then the alarm
message displays a list of up to 3 alarms. The alarms are listed in the
order they occur with the alarm activated first at the top. The
remaining alarms are available in the Alarms dialog.
14
Alarms | GO7 Operator Manual
103

Simrad GO7 Specifications

General

Resolution	800 x 480 pixels
Touchscreen	Yes
Networking	NMEA 2000
Bluetooth	Yes
Chartplotter	Yes
Display Size	7 inch
GPS Type	Internal
Wireless Connectivity	Wi-Fi
Chart Compatibility	C-MAP, Navionics
Display Type	TFT LCD
SD Card Slots	1
Sonar Compatibility	CHIRP
Radar Compatibility	Yes
Operating Temperature	-15°C to 55°C
Sonar	Broadband, CHIRP, DownScan, SideScan (with compatible transducer)
