the more echoes is displayed in the color at the strong return end of
the scale.
Palettes
You can select between several display palettes optimized for a
variety of fishing conditions.
DownScan options
Provides options for specifying the DownScan image. This menu
option is available when Overlay downscan is selected in Echo
settings dialog. For more information see "Echosounder settings" on page
81.
Pausing the Echosounder
You can pause the Echosounder, allowing you to examine the
Echosounder echoes.
This function is useful when you need to position a waypoint
exactly on the Echosounder panel, and if you are using the cursor to
measure a distance between 2 elements on the image.
Recording log data
You can record data and save the file internally in the unit, or save it
onto a card inserted into the unit's card reader. Select the Log sonar
menu option, and then Record in the Record Echo dialog.
When the Echosounder data is being recorded, there is a flashing
red symbol in the top left corner and a message appears
periodically at the bottom of the screen.
Echosounder | GO7 Operator Manual
79

Simrad GO7 Specifications

General

Resolution	800 x 480 pixels
Touchscreen	Yes
Networking	NMEA 2000
Bluetooth	Yes
Chartplotter	Yes
Display Size	7 inch
GPS Type	Internal
Wireless Connectivity	Wi-Fi
Chart Compatibility	C-MAP, Navionics
Display Type	TFT LCD
SD Card Slots	1
Sonar Compatibility	CHIRP
Radar Compatibility	Yes
Operating Temperature	-15°C to 55°C
Sonar	Broadband, CHIRP, DownScan, SideScan (with compatible transducer)
