Simrad NSE12 Installation Manual

18 | System architecture
Green
Blue
Yellow
Orange
SIMNET
Supplied with
display or accessory
Optional
accessory
PULSE RADAR
ECHOSOUNDER
NSE8 or NSE12
NSE8 or NSE12
Video 1
SimNet Starter kit
NMEA 0183NMEA 0183
Video 2
Video 1
Video 2
Cameras
RX +
TX +
TX -
RX -
RX +
TX +
TX -
RX -
BROADBAND RADAR
HD Digital Radar:
2,4,6,10 or 25 kW
Video In / Data
DVI Video Cable
Video In / Data
Ethernet 5 Pin 2m (6.5 ft)
Ethernet Adapter
5 pin to RJ45
EthernetEthernet
WEATHER
Sirius Satellite
(USA Only)
T
T
VIDEO OUT
Simrad DI10 or DI15
display’s
Note: NSE8 only connects to DI10
NSE12 only connects to DI15
DI15
From
NSE12
DI10
From
NSE8
MO15-L, MO17-L or MO19-L
Monitor
Note: dimming not controlled by NSE
OR
Ethernet 5 Pin 2m (6.5 ft)
SimNet cable 2m (6.5 ft) SimNet cable 2m (6.5 ft)
Ethernet 5 Pin 2m (6.5 ft)
Ethernet RJ45 2m (6.5 ft)
Power cable w/term
Drop cable 2 m (6 ft)
Termiator plug
7 way joiner
BSM-1
BSM-2
LSS-1
GPS ANTENNA: GS-15
AIS: NAIS300, AI50
Autopilot: AP28, AC12,
SG05
Heading Sensor: RC42
Instruments: IS20
(Graphic, Data, Wind)
Digital Switching:
CZONE
Audio: SonicHub
Controller: OP40
NMEA 2000 Engines
SIMNET
BR24 / 3G
Dual station confi guration possibilities
