Simrad NSE12 Installation Manual

Introduction | 7
Check the parts
Packaged parts list
NSE8
8.4 “ Display unit
NSE8 Bezel
NSE12
12 “ Display unit
NSE12 Bezel
NSE8 Dust cover
NSE8 Gasket
NSE12 Dust cover NSE12 Gasket
NSE8 Mounting bracket
NSE8, NSE12
Bracket knobs
NSE12 Mounting
bracket
NSE8, NSE12
2 x Ratchet wash-
ers
NSE8 Cut-out Template
212 mm (8.34”)
285 mm (11.20)
265 mm (10.40”)
CLEARANCE HOLE TO SUIT M4 MACHINE SCREW
OR DRILL PILOT HOLE TO SUIT SELF TAPPING SCREW
5 mm (0.20”)
192 mm (7.55)
NX50
192 mm (7.55”)
265 mm (10.40”)
PRODUCT OUTLINE
25 mm (1.00”)
CUTOUT
Check dimensions before cutting
NSE8, NSE12
Power cable
NSE12 Cut-out
Template
NSE8, NSE12
Video-In / Comms
Cable
NSE8, NSE12
Connector Caps
NSE8, NSE12
This Installation
Manual
NSE8, NSE12
Operation manual
NSE8, NSE12
Quick start guide
NSE8, NSE12
Cleaning cloth
NSE8, NSE12
5 x SCREW,14G x
1,PAN POZI,S/T,SS
316,BLACK
NSE8, NSE12
4 x SCREW,
8Gx1, PAN POZI,
S/T,16,LO-HEAD
SimNet Starter Kit: Includes
• SimNet 5 m (16.5 ft) cable
• SimNet 7-Prong Multi-Joiner
• SimNet Termination Plug
• SimNet 2 m (6 ft) power cable w/termi-
nator
