Simrad NSE12 Installation Manual

Spare parts | 77
Compatible BSM-1 Transducers
Part Number Description
000-0136-02 Airmar P319, plastic, low profi le, thru hull 50/200 KHz, depth/temp,
7 pin blue connector
000-0136-03 Airmar P79, plastic, In-Hull 50/200 KHz, depth only, 7 pin blue con-
nector
000-0136-04 Airmar B60, bronze, low profi le, thru hull, 50/200 KHz, depth/temp,
12° tilt, 7 pin blue connector
000-00021-001 Airmar B60, bronze, low profi le, thru hull, 50/200 KHz, depth/temp,
20° tilt, 7 pin blue connector
000-0136-05 Airmar B744V, bronze, thru hull 50/200 KHz, depth/temp/speed,
high-speed fairing block, 7 pin blue connector
000-0136-06 Airmar B164, bronze, low profi le, thru hull, 1 kW 50/200 KHz,
depth/temp, 12° tilt, 7 pin blue connector
000-0136-00 Airmar B258, bronze, thru hull, 50/200KHz, depth/temp, high-speed
fairing block, 7 pin blue connector
000-0106-82 Airmar B260, bronze, thru hull, 50/200KHz, depth/temp, high-speed
fairing block, 7 pin blue connector
000-0106-91 Airmar M260, plastic In-hull, 50/200KHz, depth only, tank kit
000-0106-77 HST - DFSBL 50/200 kHz transom-mount skimmer depth/temp
000-0099-95 TS-1BL Temperature sensor (non-networked)
000-0099-93 XT-12BL 3.65 m (12 ft) blue transducer extension cable
000-0099-94 XT-20BL 6 m (20 ft) blue transducer extension cable
000-00022-001 Cable, adapter, 6 Pin LTW to 7 Pin BLUE
SimNet accessories
Part Number Description
000-10298-001 OP40 Wired Remote
SIMKIT-1 SimNet Starter Kit: Includes
• 24005845 SimNet 5 m (16.5 ft) cable
• 24006298 SimNet 7-Prong Multi-Joiner
• 24005894 SimNet Termination Plug
• 24005902 SimNet 2 m (6 ft) power cable w/terminator
SIMKIT-2 SimNet Starter Kit with one AT10 NMEA0183 interface
• 24005936 AT10 two way general NMEA0183 to SimNet Converter
• 24005837 SimNet 2m (6 ft) cable
• 24005845 SimNet 5m (16.5 ft) cable
• 24006298 SimNet 7 Prong Multi-joiner
• 24005894 SimNet termination plug
• 24005902 SimNet 2m (6 ft) power cable w/terminator
24005829 0.3 m (1 ft) SimNet cable
24005837 2 m (6.6 ft) SimNet cable
24005845 5 m (16.6 ft) SimNet cable
24005852 10 m (33 ft) SimNet cable
44172260 SimNet In-line joiner
24005860 SimNet T-joiner (3 prong)
24006298 SimNet Multijoiner (7 prong)
24006306 SimNet Bulkhead T-connector
24005878 SimNet cable gland
24005886 SimNet protection plug
