Commission the system | 45
Commissioning checklist
The NSE has a number of advanced features which can be configured through the
settings menu.
It is recommend you become familiar with the operation of the unit using the default
settings before making any changes to these menus.
Settings menus will vary depending on the optional sensors and devices attached.
Before changing system settings make sure that all displays are powered on as a lot of
settings are global and are shared across the Ethernet network.
It is recommended to note the original settings before making adjustments or changes.
NSE related check list Refer
Page
System
Set Language 46
Set Units
Set time 46
Set Time and Date format 46
Set power control option if used. Repeat on all relevant displays 46
Data sources
Perform auto source selection 51
Perform any manual source set up 51
Set NMEA0183 baud rate and output sentences. Settings relevant to dis-
plays with NMEA0183 devices attached.
67
Set up of SimNet groups for parameters such as dimming and alarms 51
Set up SimNet source selection groups as needed or leave as default.
Default is all parameters are set to SIMRAD group
52
Any custom setup of devices such as renaming sources. Source select
advanced
52
Calibrate any dock side devices e.g SimNet depth offset
Confi rm Auto pilot interface 58
Echosounder
Set transducer type 48
Set depth offset 47
Sea temperature calibration 48
Speed calibration 48
Water speed averaging 48
Radar
Set antenna height: HD and Broadband Radar 51
Set zero bearing: HD and Broadband Radar (note, perform heading sensor
calibration fi rst
51
Set zero range (main bang): HD Radar 50
Adjust for local interference: Broadband Radar 49
Park angle: Open array HD Radar 49
Heading sensor calibration 61
AIS
Enter own ships MMSI number 68
Back up settings
Create a backup of the display settings and transfer to portable drive or SD
card
70
