Simrad NSE12 Installation Manual

Commission the system | 73
Screen capture
It is possible to capture a snap shot of the current screen
Step 1 Step 2
Enable screen capture
Create desired screen to capture
Step 3
MOB
ABC DEF
123
JKLGHI MNO
456
TUV PQRS WXYZ
7
STBY
AUTO
PWR
8
0
9
Short press on PWR button to capture
screen shot
File transfer
Step 1 Step 2
Insert a USB Flash drive or SD card
Press PAGES > 9
Browse to the desired screen shot to copy
Press MENU and select Copy
select the USB Drive or SD card as the loca-
tion to copy the fi le too.
