System architecture | 17
VIDEO /DATA
NSE Display
POWER
SIMNET
SIMNET NETWORK
Supplied with
display
or accessory
Optional
accessory
WEATHER
Amp for
ECHOSOUNDER
VIDEO OUT
Red (FUSE)
Black
Yellow
Power Control
Ext. Alarm
Video 1 (Red)
12 v DC
USA Only
USA Only
NMEA 0183
Video 2 (Green)
Simrad DI10 or DI15
display’s
Note: NSE8 only connects to DI10
NSE12 only connects to DI15
DI15
From
NSE12
DI10
From
NSE8
MO15-L, MO17-L, or MO19-L
Monitor
Note: dimming not controlled by NSE
Composite Video
12 or 24 V DC
Blue
+
_
RX +Green
Blue
Yellow
Orange
TX +
TX -
RX -
NMEA 0183
Serial port
1 x RS422 port
GPS ANTENNA: GS-15
AIS: NAIS300, AI50
Autopilot: AP28, AC12, SG05
Heading Sensor: RC42
Instruments: IS20
(Graphic, Data, Wind)
Digital Switching: CZONE
Audio: SonicHub
Controller: OP40
NMEA 2000 Engines
BROADBAND RADAR
SimNet starter kit
SimNet & NMEA 2000 devices
Power cable w/term
Drop cable 2 m (6 ft)
Termiator plug
7 way joiner
Sirius satelite weather and radio
HD Digital Radar: 2,4,6,10 or 25 kW
Power cable
Video In / Data cable
OR
Ethernet Adapter
DVI Video Cable
+
_
Ethernet 5 Pin 2m (6.5 ft)
Ethernet RJ45 2m (6.5 ft)
Ethernet 5 Pin 2m (6.5 ft)
Ethernet 5 Pin 2m (6.5 ft)
Audio cable
T
T
SimNet cable 2m (6.5 ft)
PULSE RADAR
BSM-1
BSM-2
LSS-1
BR24 / 3G
Single station con guration possibilities
