20 | System architecture
J1 J2
J3
J1 J2
J3
J1 J2
J3
Suggested system
POWER BOATS 36 ft +
T
T
T
P
P
SimNet drop cable
SimNet backbone
SimNet terminator
Ethernet
SimNet power 12 V DC
(yellow, no terminator)
RC42
AC 42
RF25
AI50
GPS Ant
VHF
VHF
DVI Cable
RS82 H/S
RS82 H/S
7 way joiner
7 way joiner
BSM-1
NEP-1
AT10-HD
Tansducer
NSE
AP28
6 kW
HD Radar
processor
RS82 BB
AP24
NSE
Third party DVI monitor
IS20 Graphic
GS15
NSE
Station 1 Station 2
Saloon
Video In
OP40 Controller
