Simrad NSE12 Installation Manual

80 | Specifi cations
Communications
NMEA0183 1 x RS422 port
Supported baud
rates
4,800, 9,600, 19,200, 38,400 Note. Port will transmit and receive
at the set baud rate
Ethernet 10/100 base Ethernet, three ports
Max number of
displays
6 in any combination NSE8 or NSE12
External connectors
(front)
x 1 USB and x 1 SD
External
Connectors (rear)
Power (power control, ext. alarm), Video-in (NMEA 0183/
Composite video x2), SimNet (NMEA2000), Network (3 x ether-
net, USB x 1, Video Out (DVI-I x 1)
Display specifi c specifi cations
NSE8 NSE12
Display size 8 “ Diagonal Display size 12.1” Diagonal
Display resolution 800 x 600 Display resolution 1024 x 768
Brightness (max) 1500 nits Brightness 1500
Contrast ratio 850:1 Contrast ratio 600:1
Viewing angle 60 deg. above and below normal axis with: >75% nominal bright-
ness >100:1 contrast ratio
60 deg. side to side about normal axis with: >75% nominal
brightness >100:1 contrast ratio
Height 212 mm (8.35") Height 266 mm (10.47”)
Width 285 mm (11.22") Width 356 mm (14.01”)
Depth 111 mm (4.38") Depth 122.7 mm (4.83”)
Weight 3.2 kg (7 lb) Weight 5.5 kg (11.5 lb)
Current Draw (in
Watts) at 12/24VDC
Display only
21.6W or 1.8A @
12.0 V DC / 21.6W or
0.9A @ 24VDC
Current Draw (in
Watts) at 12/24 VDC
Display only
33.6W or 2.8A
@ 12.0 V DC /
33.6W or 1.4A @
24VDC
