4
EN
4. Technical data
- 45 -
951-180-083-EN
Version 01
4.2.2 VPK progressive metering device with 2/2 directional sole-
noid valve for oil and grease, attachment 13
4.2.3 VPK progressive metering device with 3/2 directional
solenoid valve for oil and grease, attachment 14
VPK with 2/2 directional solenoid valve, Table 8
VPK progressive metering device with 2/2 directional sole-
noid valve
For further technical data, see VPK basic design
Thread connection: Inlet: G1/4"
Media temperature Max. +70 °C
Hydraulic system
Operating pressure max. Grease 400 bar
Lubricant Greases up to NLGI Grade 2
Volumetric flow Max.15 l/min
Electrical system
Directional solenoid
valve
Valve function 2/2 directional solenoid valve
Type/operation Seat valve, double-sided blocking
Basic position De-energized closed (NC)
Voltage 24 V DC
Rated current 0.83 A
Rated output 23 W
ON-time 100% ED (at max. +35°C)
Protection class IP 67
Electrical connection 10 m cable, 3x0.5 mm
2
EX protection class of VPK metering device with 2/2 directional
solenoid valve
Device labeling
II 2G IIB T4 Gb / -35...+40°C
II 2D IIIC T135°C Db / -35...+40°C
VPK with 3/2 directional solenoid valve, Table 9
VPK progressive metering device with 3/2 directional solenoid
valve
For further technical data, see VPK basic design
Thread connection: Inlet: G1/4"
Media temperature Max. +70 °C
Hydraulic system
Operating pressure max. Grease 400 bar
Lubricant Greases up to NLGI Grade 2
Volumetric flow Max.15 l/min
Electrical system
Directional solenoid valve
Valve function 3/2 directional solenoid valve
Type/operation Seat valve, double-sided blocking
Basic position De-energized C connected to B, A blocked
Voltage 24 V DC
Rated current 0.83 A
Rated output 23 W
ON-time 100% ED (at max. +35°C)
Protection class IP 67
Electrical connection 10 m cable, 3x0.5 mm
2
EX protection class of VPK metering device with 3/2 directional
solenoid valve
Device labeling
II 2G IIB T4 Gb / -35...+40°C
II 2D IIIC T135°C Db / -35...+40°C
