SKF VP Series User Manual

EN
6. Assembly
- 56 -
951-180-083-EN
Version 01
Fig. 13 VP progressive metering device with inductive NAMUR sensor Fig. 12 VP progressive mete-
ring device with cycle indicator
6.3.3 VP progressive metering device with
cycle switch, monitoring type ZY
6.3.4 VP progressive metering device with inductive NAMUR sensor, moni-
toring type ZS (electric monitoring)
26
24-38X
X
-X
X
X
X
-A
TEX
HM
BM
LM
24-38X
X-XXXX-A
TEX
Made in Germany
SKF Lubrication Systems Germany GmbH
24-38XX-XXXX
XYZ KW/JJ
II 2D c IIIC T135°CDb
II 2G c IIC T4Gb
36
HM
BM
LM
Minimum mounting dimensions
BM = Width: 130 mm
HM =
Height: 70 mm
LM =
Length: L2+40 mm
Minimum mounting dimensions
BM = Width: 130 mm
HM =
Height: 70 mm
LM =
Length: L2+60 mm
