6. Assembl
y
- 71 -
951-180-083-EN
V
ersion 01
Fig. 25
VPB
progr
essive
metering device
in
basic design
6.5
VPB port dimensions, assembly holes, a
nd minimum mounting dimensions
6.5.1
VPB in basic design
Minimum mounting dimensions
BM
=
Width:
100
mm
HM
=
Height:
70
mm
LM
=
Length:
L+40
mm
BM
HM
LM
24-3820-X
XXX
-ATEX
24-3820-XXXX
5
L
60
72
20
20
7
22
30
15
70
72
