Fig. 20 VPK progressive metering device with inductive NAMUR sensor Fig. 19 VPK progressive mete-
ring device with cycle indicator
6.4.3 VPK progressive metering device
with cycle switch, monitoring
type ZY
6.4.4 VPK progressive metering device with inductive NAMUR sensor, monitoring type
ZS (electric monitoring)
Minimum mounting dimensions
BM = Width: 130 mm
HM =
Height: 50 mm
LM =
Length: L2+30 mm
HM
BM
LM
24-381
0-
XXX
X
-
AT
EX
26
Minimum mounting dimensions
BM = Width: 130 mm
HM =
Height: 50 mm
LM =
Length: L2+60 mm
HM
BM
LM
24-3810-
XXXX-A
TEX
36
24-3810-XXXX
