6
EN
6. Assembly
- 63 -
951-180-083-EN
Version 01
6.4.2 VPK tightening torques
IMPORTANT
Inlet and outlet fittings - see Chapter 14.2.
VPK dimensions
Thread connection
VPKM
Inlet:
M10x1
Outlet:
M10×1
VPKG
G1/8" G1/8"
Type
Number of
progressive
metering
device
sections
Number
of possible
outlets
L1 L2 Weight
[mm] [mm] [kg]
VPKM-3 / VPKG-3
1)
3 6
68.4 79.9 0.99
VPKM-4 / VPKG-4 4 8
84.6 96.1 1.18
VPKM-5 / VPKG-5 5 10
100.8 112.3 1.38
VPKM-6 / VPKG-6 6 12
117.0 128.5 1.57
VPKM-7 / VPKG-7 7 14
133.2 144.7 1.77
VPKM-8 / VPKG-8 8 16
149.4 160.9 1.96
VPKM-9 / VPKG-9 9 18
165.6 177.1 2.16
VPKM-10/VPKG-10 10 20
181.8 193.3 2.35
1) This progressive metering device must be installed with check valves.
The specified torques must be observed during
assembly and repair.
Tie-rod (starter plate) (M8) 2.4 Nm ± 0.1 Nm
Nut for tie-rod (M8) 12 Nm ± 1.0 Nm
Inlet and outlet fittings
Type of fitting
Sealing with O-ring 10 Nm ± 1.0 Nm
Sealing with EOlastic ring 10 Nm ± 0.1 Nm
Sealing with copper or alu-
minum ring
15 Nm ± 1.5 Nm
Sealing by sealing edge,
with Loctite 243
15Nm ± 1.5 Nm
Sealing with
Conical nipple
1
)
15Nm ± 1.5 Nm
Plug screw M6x10 10Nm+1 Nm
1) Minimum of 9 Nm at drying time of > 1h
sufficient
