6. Assembl
y
- 54 -
951-180-083-EN
V
ersion 01
Fig. 11
VP
progr
essive
metering device
in
basic design
6.3
VP port dimensions, assembly holes, a
nd minimum mounting dimensions
6.3.1
VP in basic design
BM
HM
LM
24-38XX-
X
XXX
-ATEX
Made in Germany
SKF Lubrication Systems Germany GmbH
24-38XX-XX
XX
XYZ
KW/JJ
II 2D c IIIC T135°CDb
II 2G c IIC T4Gb
22
40.5
SW5
SW13
10.1
28.5
35
6.5
72
80.5
1
7
L1 ±2
L2 ±2
max.5
24
24
Ø
7
10.5
6
Minimum mounting dimen-
sions
BM
=
Width:
100
mm
HM
=
Height:
70
mm
LM
=
L
ength:
L2+40
mm
53
55
