6. Assembly
- 73 -
951-180-083-EN
Version 01
Fig. 27 VPB progressive metering device with inductive NAMUR sensor Fig. 26 VPB progressive mete-
ring device with cycle indicator
6.5.4 VPB progressive metering device with inductive NAMUR sensor, monitoring type
ZS (electric monitoring)
6.5.3 VPB progressive metering device
with cycle switch, monitoring type ZY
HM
BM
LM
24-3820-X
X
X
X-
ATEX
25
24-3820-XXXX
Minimum mounting dimen-
sions
BM = Width: 160 mm
HM =
Height: 70 mm
LM =
Length: L+40 mm
Minimum mounting dimen-
sions
BM = Width: 140 mm
HM =
Height: 70 mm
LM =
Length: L+60 mm
HM
BM
LM
24-3820-X
XX
X-ATEX
35
24-3820-XXXX
