4
EN
4. Technical data
- 47 -
951-180-083-EN
Version 01
4.3 VPB volume data for metering device outlets
4.3.1 Basic design of VPB progressive metering device
Volume data for VPB metering device outlets, Table 11
Max. inlet volumetric flow 400cm
3
/min
Nominal volume Minimum volume
1
)
(at maximum stroke) (at compulsory stroke, design value
only under difficult conditions)
Volume per cycle and
outlet
Volume per cycle and outlet
[cm
3
] [cm
3
]
0.20 0.13
1) See explanation in Chapter 3.3, Information on volume data.
Progressive metering device VPB, basic design, Table 12
VPB Basic design with terminal for equipotential bonding
Type hydraulically controlled
Mounting position Any
Ambient temperature range -25 to +110 °C
- with cycle indicator -20 to +70 °C
Inlet and outlet threads
VPBM (metric thread) M10x1
VPBG (inch thread) G1/8
Material
Steel, galvanized, optional stainless
Hydraulic system
Operating pressure max.: Oil 200 bar, grease 300 bar
Volume per outlet and cycle See Table 11
Lubricant Mineral oils, greases based on mineral oil,
environmentally friendly and synthetic oils
and greases
Dynamic viscosity > 12 mm
2
/s
Worked penetration ≥ 265 x 0.1 mm (up to NLGI Grade 2)
