SKF VP Series User Manual

EN
6. Assembly
- 74 -
951-180-083-EN
Version 01
Fig. 29 VPB progressive metering device with
3/2 directional solenoid valve
Fig. 28 VPB progressive metering device
with 2/2 directional solenoid valve
6.5.5 VPB progressive metering device with 2/2 directional
solenoid valve
6.5.6 VPB progressive metering device with 3/2 directional sole-
noid valve
Minimum mounting dimensions
BM = Width: 100 mm
HM =
Height: 180 mm
LM =
Length: L+60 mm
HM
BM
LM
820-XXXX-ATEX
17
15
32
153
5
60~54
20
20
60
7
G1/8
24-3820-XXXX
19
B
A
Minimum mounting dimensions
BM = Width: 100 mm
HM =
Height: 180 mm
LM =
Length: L+60 mm
HM
BM
LM
BA
C
G1/8
G1/8
17
15
32
153
20
33
5
60~54
20
20
60
24-3820-XXXX
29
07
Seat valve, double-sided
blocking, de-energized C
connected to B, A blocked
Seat valve, double-sided
blocking, de-energized
closed
