Description/Location
Fan-Cooled Mode ls
MODE L FUS E DE SCRIPTION LOC AT ION
M anual start 20 A
Ground protection
Underneath console
30 A
Charging system
Top o f battery
Ele ctri c start
20 A
Ground protection
Underneath console
G round Prot ection
CAUTION: Thi s fuse s hould a lw ay s be dis c onnected bef ore do-
ing any maintenance under the hood. This is to prevent any un-
expected electrical activation.
mmo2007-002-009_a
LH SIDE OF ENGINE COMPARTMENT — ALL FAN COOLED MODELS
1. Ground protection fuse
2. Headlamp beam aiming knob
104
