DRIVEN PULLEY NOTCHES
N O TE: Notches ar e there on the driven pulley for reference purpose
only and the desired adjustment can be attained at any point.
DrivePulleyAdjustment
WARNING
Rem ove tether cord cap before performing any maintenance
or adjus tm ent, unl es s othe r wi se spec ifi ed. Vehicl e must b e
par ked in a saf e place, a way from the trail.
General
The d riv e pulley is factory calibrated to transmit maximum engine
power at a pr edefined RP M. Refer to SPE CIFICATIONS section in
th is guide . Fac tors s uch as ambie nt temperature, a ltit ude or su rface
condition may vary this critical engine RPM thus affectin g snowm o-
bile efficiency.
This adjustable drive pulley allows setting maximum engine RPM in
th e v ehicle to mai nta in maximum p ower.
Calibration screws should be adjusted so that actual m aximum en-
gine RPM in vehicle matches with the maximum horsepower RPM.
N O TE: Use pr ecision digit al tachom eter for engine RPM adjustment.
N O TE: The adjustment has an effect on high RPM only.
Calibration screw has a notch on top of its head.
208
