4) Temperature Gauge
The gauge indic ates engine coolant temperature. The needle moves
to the normal range as engine warms. Under all r iding conditions,
the needle should stay within this range. If needle moves int o the
overheat range, reduce snowmobile speed and run snowmobile in
loose snow or stop engine immediately.
A32A27A
2
1
TYPICAL
1. Normal
2. Overheat
5) Thrott le Lever
Located on the right hand side of handlebar and desi gned to be
thum b activated. W hen squeezed, it increases the engine speed
and engages the transmission. When released, engine speed
re turns a utomatica lly to i dle.
WARNING
Test th e thr o ttle lever operation ea ch time befor e sta r ting the
eng ine . The le ve r m ust retu rn to its ori gin al pos iti on onc e re-
leased. Otherwise, do not start engine.
78
