TYPICAL — MODELS WITH SPEEDOMETER
1. Reverse pilot lamp
2. DESS/RER pilot lamp
3. High beam pilot lamp (blue)
4. Oil pilot lamp
5. Low battery voltage pilot lamp
6. Engine management system (EMS) pilot lamp
7. Engine overheat warning lamp (red)
8. Mode Button
9. Multifunction dis play
Pi lot L amps
Reve rse (DESS/R ER)
This pilot lamp will light up when reverse is selected.
High Beam
Light s when headlamp is on HIGH beam position.
Injection Oil
This pilot lam p will glow up when injection oil level is low. Stop ve-
hicle in a safe place then, replenish injection oil reservoir.
Liquid Cool ed Mode ls Only
Low B attery Voltage
This lamp will light up to indicate a low battery voltage condition (on
so e quippe d models
). See an authorized SKI-DOO dealer as soon
as possible.
