SMA SUNNY WEBBOX User Manual

Device Overview SMA Solar Technology AG
18 SWebBox-BEN111033 User Manual
5.2 Overview of the Connection Area
SYSTEM flashes red Sunny WebBox is starting.
glows red An error has occurred in the Sunny WebBox.
glows green Sunny WebBox is operational.
POWER glows green Sunny WebBox has power.
off Sunny WebBox does not have power.
Item Description
A Connection for GSM antenna cable (optional)
B Connection for the plug-in power supply
CJumper socket J1
DSMACOM
E AUXCOM (no function)
FJumper socket J2
GModem connection
H USB connection client (no function)
I USB connection host (no function)
J Network connection
KSD card slot
LED name Status Meaning
