Technical Data SMA Solar Technology AG
96 SWebBox-BEN111033 User Manual
17 Technical Data
17.1 Sunny WebBox
Mechanical Data
Power Supply
Environmental Conditions
Communication
Other
Width x height x depth 255 mm x 130 mm x 57 mm
Weight 750 g
Typical power consumption 4 W
Maximum power consumption 10 W
Ambient temperature –20 °C ... +65 °C
Relative air humidity 5 % … 95 %, non-condensing
Degree of protection
*
*
Degree of protection according to DIN 60529
IP20
Mounting location Indoors
Inverters other than Sunny Central RS485, maximum 50 inverters
Sunny Central RS485, 10/100 Mbit Ethernet,
maximum 50 inverters
Computer 10/100 Mbit Ethernet
Modem
*
*
optional
Analog, GSM
RS485 communication range 1 200 m
Ethernet communication range 100 m
Languages for the software user interface German, English, French, Italian, Spanish, Greek,
Korean, Portuguese, Czech, Dutch
Internal ring buffer 8 MB
Additional memory via SD memory cards
*
*
optional
128 MB / 512 MB / 1 GB / 2 GB
